SCUDO PANEL VAN
If you are looking for the maximum balance between cabin spaciousness and load volumes, this is the perfect version for you.
Choose your Scudo engine
You can choose the Scudo engine that suits you best: one with a diesel engine and a completely new all-electric one, without compromises on vehicle performance.
Compact on the outside, big on the inside.
Despite the compactness of the vehicles exterior, with a height of only 190 cm, the available volume is incredibly large, with up to 6,6 m3 of loading capacity and up to 1.4 ton of payload.
Comfortable like your car
Feel as comfortable as driving a car. The comfortable driving position and the compactness of the Scudo allow you to have a stress-free workday, even on longer journeys.
Multifunctionality at hand
Discover all the options to modulate the Scudos interiors. Thanks to the new Magic Cargo functionality, the new Scudo offers you generous volume and loading solutions.
THE ELECTRIC PERFORMANCE YOU'VE BEEN LOOKING FOR
The electric motor of the Scudo will make you experience an uncompromising new level of performance. In addition, you can choose between different batteries, 49 or 75 kWh, according to your needs. As for diesel engines, Scudo features a wide range of engines with four different engine types, with the 2.0 liter version being combined with the new 8-speed autonomous transmission.
Electric without compromises
In addition to great performance, you'll have no compromise on interior space and reduced CO2 emissions, thus having free access to the low emissions zones*
*Check regulations in your city.
State-of-the-art diesel engine
Three power steps and dual transmission available: manual or 8-speed automatic.
Great load capacity
Benefit from the same load volume and payload both in the diesel and in the electric vehicle, only on standard versions.
Scudo Multijet
In the new Scudo van you have a choice of four top-of-the-range internal combustion engines that stand out for their efficiency and performance.
-
Displacement
1499 cc
-
N° of cylinders, layout
4, in line
-
Fuel System
Electronically controlled Common Rail Multijet3 direct injection with variable geometry turbocharger and intercooler
-
Power and torque
120 hp (88kW) at 3750 rpm
300 nm at 1750 rpm -
Emission Level
Euro 6D-Final
-
Engine Coupling and Gears
Dry single plate clutch with hydraulic release device
Manual 6+R
-
Displacement
2000 cc
-
N° of cylinders, layout
4, in line
-
Fuel System
Electronically controlled Common Rail Multijet3 direct injection with variable geometry turbocharger and intercooler
-
Power and torque
145 hp (106kW) at 3750 rpm
340 nm at 1750 rpm -
Emission Level
Euro 6D-Final
-
Engine Coupling and Gears
Dry single plate clutch with hydraulic release device Manual 6+R
-
Displacement
2000 cc
-
N° of cylinders, layout
4, in line
-
Fuel System
Electronically controlled Common Rail Multijet3 direct injection with variable geometry turbocharger and intercooler
-
Power and torque
145 hp (106kW) at 3750 rpm
370 nm at 1750 rpm -
Emission Level
Euro 6D-Final
-
Engine Coupling and Gears
Torque converter, with electronic electro-hydraulic control system
Automatic 8+R
-
Displacement
2000 cc
-
N° of cylinders, layout
4, in line
-
Fuel System
Electronically controlled Common Rail Multijet3 direct injection with variable geometry turbocharger and intercooler
-
Power and torque
177 hp (130kW) at 3750 rpm
400 nm at 1750 rpm -
Emission Level
Euro 6D-Final
-
Engine Coupling and Gears
Torque converter, with electronic electro-hydraulic control system
Automatic 8+R
The uncompromising electric driving force propulsion you can rely on.
Be ready to be surprised by a smoother and more responsive driving experience that allows you to move freely even in areas close to traffic and city center. Thanks to the E-Scudo engine you can achieve up to 352 Km with 75 kWh battery* and a maximum speed of 130 km/h. You'll also have reduced charging times** and, of course, reduced carbon footprint to almost zero.
And all this without any compromise on volumes. The new E-Scudo guarantees up to 1 ton of payload.
*75 kWh battery in WLTP Combined Range
**Up to 100 kWh with DC charge
And all this without any compromise on volumes. The new E-Scudo guarantees up to 1 ton of payload.
*75 kWh battery in WLTP Combined Range
**Up to 100 kWh with DC charge
49 kWh
The standard battery allows you to reach a maximum speed of 130 km/h and a torque of 270 Nm immediately available. With the 49 kWh battery you will have up to 224 km* of maximum autonomy guaranteed.
**WLTP combined range
Discover your version
SCUDO PANEL VAN
Dimensions
The new Scudo range includes different versions, lengths, and load solutions to meet your most specific needs. Choose the ideal Scudo for you and your business.
Specs
Scudo Panel van
Scudo Crew
Scudo Platform
Scudo Combi M1
External length (m)
4.98 / 5.33
4.98 / 5.33
Max 5.46 with hinges and accessorizes
4.98 / 5.33
External height (m)
1.90 / 1.94
1.90 / 1.94
Max 2.5 without spoiler / 2.6 with spoiler
1.90 / 1.94
Load volume (m3)
-
-
-
-
Scudo Standard
From 5,3 to 5,8
From 3,2 to 4,7
-
From 0,7 to 4,2
Scudo Maxi
From 6,1 to 6,6
From 4 to 5,5
-
From 1,3 to 4,9
Load compartment: maximum length (m)
-
-
-
-
Scudo Standard
From 2,51 to 3,67
2,02
-
From 0,6 to 2,41
Scudo Maxi
From 2,86 to 4,02
2,37
-
From 0,96 to 2,76
Load compartment: maximum height (mm)
1397
1397
-
1397
Load compartment: width of rear door (mm)
1282
1282
-
1282
Load compartment: PPT (tons)
From 1 to 1,4
Max. 1.18
From 1,2 to 1,4
-
Payload (tons)
From 2 to 3
6
From 2 to 3
Up to 9
VERSIONS
For over 40 years, we have been repaying your trust with reliability, dedication and 10,000 available versions. Your mission becomes our mission whether you are transporting goods, people or if you have specific needs.
Safety and driving assistance
Up to 13 active and passive safety features
The new Fiat Professional Scudo van comes equipped with a state-of-the-art ecosystem of safety features that will support you while driving, making every journey as safe as possible.
ADAS
Pure driving pleasure
The comfort that you were looking for
The new Scudo van is a commercial vehicle that offers all the essentials for any business trip: is versatile, functional and agile. The different possible configurations of seats and steering wheel and the car-like driving position will provide you maximum comfort everyday - even on long journeys.
LET THE NEW SCUDO IMPROVE YOUR EVERYDAY LIFE
MAGIC CARGO
EAT AND WORK
A welcoming, comfortable and versatile cabin
Did you expect it to be this spacious? The new Scudo offers space and cabin management solutions designed exclusively to put you in the best working conditions, even in the most challenging situations.
MAGIC CARGO
The new Scudo boasts a state-of-the-art system for loading bulky materials that further accentuates the distinctive versatility of this model. With the Magic Cargo you'll be able to extend the loading area: up to 3.67 m in the standard version, and a maximum of 4.02 m in the Maxi version. In addition, you'll be able to adjust the front seat and use it as a table for computer and tablet or a support for having lunch in maximum comfort.
TECHNOLOGY
New tech features for you
The new Fiat Professional Scudo comes equipped with new connectivity and infotainment features that are essential for you and that will help you to better face the day-to-day challenges of your work.
Infotainment
1/6
5" & 10" TOUCHSCREEN RADIO
The infotainment system features a 5'' touchscreen DAB radio with one USB port or a 10" color touchscreen display, a DAB car system, an MP3 player, 4 USB input and WIFI connection. In addition, the predisposition for Apple CarPlay and Android Auto™ systems allows you to stay connected to your smartphone safely and without being distracted from driving.
2/6
Apple CarPlay
CarPlay is the fastest and safest way to use your iPhone while working on your vehicle. Stream everything you need directly from your iPhone to the vehicle display. You can get directions, make calls, send and receive messages and listen to music, whilst keeping your attention to the driving. CarPlay also features Siri voice control and it also works with your vehicle's controls: knobs, buttons, touchpad or touchscreen. All the apps supported by CarPlay have been designed to be used easily and in an accessible way, so you don't need to take your eyes off the road.
3/6
Android Auto™
With Android Auto™, all your apps are shown on the radio screen interface, allowing you to access all you content and use Google Maps and Google Play Music safely and easily. You can access it quickly thanks to voice commands, buttons on the steering wheel or via the touch screen. Thanks to these features, the driver can always stay focused on the road. Google Play and Android Auto have registered trademarks of Google LLC.
4/6
Cluster paired with 5'' radio
The new Fiat Professional Scudo as an innovative digital cluster paired with 5" display that contains the most important parameters relating to driving. The screen shows the driver the main information, such as speed and fuel consumption, but also the safety systems in function and speed limits.
5/6
Digital cluster paired with 10'' radio
The digital cluster of the electric vehicle on the other hand will show you all the information relating to the electric motor as well as battery charge levels.
6/6
Connected Services: the support you've been waiting for!
2 PACKS available:
Connect ONE offers assistance in case of breakdowns and accidents 7 days a week, 24 hours a day. Preventive Maintenance, a Fleet management service, designed to monitor and optimize the health of the vehicle, is included for 4 years for all MY 24 commercial vehicles.
Connect PLUS offers all services related to navigation and remote control functions. You can find 2 different optional connected services:
- My Wifi, to benefit from wifi in the car and share this functionality with up to 8 passengers and,
- My Alert, to receive a real-time alert via the app when the vehicle is moved without authorization or removed.
Connect ONE offers assistance in case of breakdowns and accidents 7 days a week, 24 hours a day. Preventive Maintenance, a Fleet management service, designed to monitor and optimize the health of the vehicle, is included for 4 years for all MY 24 commercial vehicles.
Connect PLUS offers all services related to navigation and remote control functions. You can find 2 different optional connected services:
- My Wifi, to benefit from wifi in the car and share this functionality with up to 8 passengers and,
- My Alert, to receive a real-time alert via the app when the vehicle is moved without authorization or removed.
FIAT ULYSSE
If your mission is to transport passengers around every day, there is a version for you too.
Discover the Fiat Ulysse, ideal for shuttle services, taxis, and hotels.
Authentic Accessories powered by Mopar®
Meet the specific needs of your business with Fiat Professional authentic accessories, designed exclusively for your new Scudo.
Dedicated seat cover
Protect your seats from fading due to repetitive use and exposure to light with the resistant Alix wrap and weft cloth covers.
