Choose your Scudo engine
You can choose the Scudo engine that suits you best: one with a diesel engine and a completely new all-electric one, without compromises on vehicle performance.
Compact on the outside, big on the inside.
Despite the compactness of the vehicles exterior, with a height of only 190 cm, the available volume is incredibly large, with up to 6,6 m3 of loading capacity and up to 1.4 ton of payload.
Comfortable like your car
Feel as comfortable as driving a car. The comfortable driving position and the compactness of the Scudo allow you to have a stress-free workday, even on longer journeys.
Multifunctionality at hand
Discover all the options to modulate the Scudos interiors. Thanks to the new Magic Cargo functionality, the new Scudo offers you generous volume and loading solutions.
THE ELECTRIC PERFORMANCE YOU'VE BEEN LOOKING FOR
The electric motor of the Scudo will make you experience an uncompromising new level of performance. In addition, you can choose between different batteries, 49 or 75 kWh, according to your needs. As for diesel engines, Scudo features a wide range of engines with four different engine types, with the 2.0 liter version being combined with the new 8-speed autonomous transmission.
Electric without compromises
In addition to great performance, you'll have no compromise on interior space and reduced CO2 emissions, thus having free access to the low emissions zones*
*Check regulations in your city.
State-of-the-art diesel engine
Three power steps and dual transmission available: manual or 8-speed automatic.
Great load capacity
Benefit from the same load volume and payload both in the diesel and in the electric vehicle, only on standard versions.
Scudo Multijet
In the new Scudo van you have a choice of four top-of-the-range internal combustion engines that stand out for their efficiency and performance.
-
Displacement
1499 cc
-
N° of cylinders, layout
4, in line
-
Fuel System
Electronically controlled Common Rail Multijet3 direct injection with variable geometry turbocharger and intercooler
-
Power and torque
120 hp (88kW) at 3750 rpm
300 nm at 1750 rpm -
Emission Level
Euro 6D-Final
-
Engine Coupling and Gears
Dry single plate clutch with hydraulic release device
Manual 6+R
-
Displacement
2000 cc
-
N° of cylinders, layout
4, in line
-
Fuel System
Electronically controlled Common Rail Multijet3 direct injection with variable geometry turbocharger and intercooler
-
Power and torque
145 hp (106kW) at 3750 rpm
340 nm at 1750 rpm -
Emission Level
Euro 6D-Final
-
Engine Coupling and Gears
Dry single plate clutch with hydraulic release device Manual 6+R
-
Displacement
2000 cc
-
N° of cylinders, layout
4, in line
-
Fuel System
Electronically controlled Common Rail Multijet3 direct injection with variable geometry turbocharger and intercooler
-
Power and torque
145 hp (106kW) at 3750 rpm
370 nm at 1750 rpm -
Emission Level
Euro 6D-Final
-
Engine Coupling and Gears
Torque converter, with electronic electro-hydraulic control system
Automatic 8+R
-
Displacement
2000 cc
-
N° of cylinders, layout
4, in line
-
Fuel System
Electronically controlled Common Rail Multijet3 direct injection with variable geometry turbocharger and intercooler
-
Power and torque
177 hp (130kW) at 3750 rpm
400 nm at 1750 rpm -
Emission Level
Euro 6D-Final
-
Engine Coupling and Gears
Torque converter, with electronic electro-hydraulic control system
Automatic 8+R
Dimensions
The new Scudo range includes different versions, lengths, and load solutions to meet your most specific needs. Choose the ideal Scudo for you and your business.
Specs
Scudo Panel van
Scudo Crew
Scudo Platform
Scudo Combi M1
External length (m)
4.98 / 5.33
4.98 / 5.33
Max 5.46 with hinges and accessorizes
4.98 / 5.33
External height (m)
1.90 / 1.94
1.90 / 1.94
Max 2.5 without spoiler / 2.6 with spoiler
1.90 / 1.94
Load volume (m3)
-
-
-
-
Scudo Standard
From 5,3 to 5,8
From 3,2 to 4,7
-
From 0,7 to 4,2
Scudo Maxi
From 6,1 to 6,6
From 4 to 5,5
-
From 1,3 to 4,9
Load compartment: maximum length (m)
-
-
-
-
Scudo Standard
From 2,51 to 3,67
2,02
-
From 0,6 to 2,41
Scudo Maxi
From 2,86 to 4,02
2,37
-
From 0,96 to 2,76
Load compartment: maximum height (mm)
1397
1397
-
1397
Load compartment: width of rear door (mm)
1282
1282
-
1282
Load compartment: PPT (tons)
From 1 to 1,4
Max. 1.18
From 1,2 to 1,4
-
Payload (tons)
From 2 to 3
6
From 2 to 3
Up to 9
Authentic Accessories powered by Mopar®
Meet the specific needs of your business with Fiat Professional authentic accessories, designed exclusively for your new Scudo.
Dedicated seat cover
Protect your seats from fading due to repetitive use and exposure to light with the resistant Alix wrap and weft cloth covers.
